Compact 10.7W emergency LED driver with selectable color temperature and adjustable lumen outputs, ideal for linear LED fixtures.
Key Features and Benefits
- Universal 120-277V, 50/60 Hz input
- Long-life, maintenance-free, rechargeable lithium iron phosphate battery
- 90-minute minimum emergency operating time
- Output short/overcurrent protection with electronic limiting
- Class 2 Compliant output classification
- Surge protection per C62.41 (TVS)
- 24-hour maximum battery recharge time
- Slim, low-profile galvanized steel housing
- LED illuminated test switch
- Designed for normally-on, normally-off, or switched load fixtures
Specifications
- Input Voltage: 120-277V
- Input Current: 0.087A
- Input Power: 5.7W
- Output Voltage: 20-50V
- Output Power: 10.7W
- Output Current: 535-214mA
- UL Listed for factory or field installation
- Suitable for damp locations (10°C – 55°C)
- Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State codes
- Certified to CEC under Title 20 regulations
Common Uses
Ideal for converting new or existing LED fixtures into unobtrusive emergency lighting, suitable for installation inside linear LED fixtures.
