3″ LED Cylinder, Pendant Mount, 13W, 0~10V Dimming, 80/90 CRI

The WCED-3DP Series 3″ LED Cylinder Pendant Mount is a versatile lighting solution designed for both indoor and outdoor applications. It offers adjustable lumen output and selectable color temperature, making it a significant addition to any lighting project.

Key Features and Benefits

• 80 or 90 CRI with color temperatures in 3000K, 3500K, or 4000K.
• Wet Location, IP65 Rated.
• Dimming with most Triac and ELV dimmers or 0-10V dimmers.
• Optional Emergency Drivers available.

Specifications

• Input Voltage: 120/277V
• Wattage: 13W
• Lumen Output: 1,160 lm
• Efficacy: 89.2 lm/W
• Beam Angle: 36°
• CRI: 80, 90
• CCT: 3000K, 3500K, 4000K
• Dimming: Triac, ELV, or 0-10V
• Environment: Wet Location

Common Uses

Ideal for outdoor applications such as commercial building exteriors, pathways, and architectural lighting.
