The LT-WCED-4SDP-17-ZTDOB Series is a part of the innovative 4″ Square LED Cylinder range, known for its adaptability in both ceiling and pendant mount applications. Engineered to withstand harsh outdoor conditions, these cylinders are IP65 rated for wet locations.
Key Features and Benefits
- Constructed from all aluminum with a powder-coated finish in white, or black.
- Selectable color temperatures: 3000K, 3500K, and 4000K.
- CRI options of 80 or 90 for superior color rendering.
- Wet location and IP65 rated ensuring durability in outdoor settings.
- Compatible with most Triac, ELV, and 0-10V dimmers for adjustable brightness.
- Optional emergency drivers available for safety lighting.
Specifications
- Input Voltage: 120/277V
- Wattage: 17W
- Lumen Output: 1,415 lumens
- Efficacy: 83.2 LPW
- Beam Angle: 36°
- Operating Temperature: -22°F to 104°F (-30°C to 40°C)
Common Uses
Ideal for outdoor environments such as building exteriors, pathways, and wet locations where reliable and efficient lighting is essential.
