The Halco TruBlu™ Mesh Passive Infrared Sensor-Controller is a compact, fixture-mounted wireless control solution designed for modern high bay and low bay lighting systems. As part of Halco’s TruBlu controls lineup, it combines PIR occupancy sensing, daylight response, and Bluetooth Mesh networking to simplify intelligent lighting control without hardwired communication.
Key Features and Benefits
- Bluetooth® NLC certified platform supports multi-vendor interoperability for scalable smart lighting projects
- Integrated PIR motion sensing and photocell enable occupancy-based and ambient light-based control strategies
- Single-channel 0-10V continuous dimming supports high-end trim, zoning, and energy-saving light level control
- Fixture-ready 3.5mm audio jack base and quick connector streamline installation and commissioning
- Reliable operation in demanding environments from -20°C to 45°C for indoor and outdoor use
- DLC Listed design helps support utility rebate and code-driven project requirements
Specifications
- Input Voltage: 12-24VDC
- Current Consumption: 20mA max
- Dimming Output: 0-10VDC, 1-channel
- Mounting Height: 20′-40′ (6.1-12.2m)
- Maximum Sensor Coverage: 80′ diameter (24.4m)
- Maximum Bluetooth Range: 100′ (30.4m)
- Lens Type: High Bay Lens (H)
- Housing Color: Black
Common Uses
Ideal for warehouses, gymnasiums, manufacturing spaces, distribution centers, and other commercial or industrial facilities using high/low bay luminaires that require wireless occupancy and daylight-responsive dimming control.
