The RP Lighting and Fans WCD-70 is a dedicated wall-mounted control and canopy receiver kit designed for compatible DC motor ceiling fans. As part of the WCD series, it delivers convenient fan and light operation from a fixed wall location without requiring batteries. This control solution is an important accessory for streamlined residential and light commercial fan installations.
Key Features and Benefits
- 5-speed fan operation for flexible comfort control throughout the day
- Built-in forward/reverse function to support seasonal airflow changes
- Integrated fan and light on/off control from one wall station
- No-battery design reduces maintenance and simplifies long-term use
- Includes matching white faceplate for a clean finished appearance
- UL Listed for dry locations and backed by a 1-year limited warranty
Specifications
- Model: WCD-70 (for use with 1070W fan)
- Input Voltage: 120V AC
- Frequency: 60Hz
- Maximum Load: 400W | 3.5A (fan and light)
- Included Components: (1) wall control and (1) canopy receiver
- Wall Plate Dimensions: 2-3/4″ W x 4-1/2″ H x 1-5/8″ D
- Interior Dimensions: 1-5/16″ W x 2-7/8″ H
- Mounting: Indoor use only (dry location)
Common Uses
Ideal for indoor ceiling fan installations in homes, apartments, hospitality spaces, and similar dry environments where users need convenient wall-based control of fan speed, blade direction, and connected lighting.
