The Prizm Lighting LED-DRJ Series 300W 12V DC Constant Voltage Driver is a robust, high-reliability power supply designed for demanding LED lighting installations. With its universal 100-277V AC input and durable, slim aluminum housing, this driver is perfect for both indoor and outdoor applications where wet location rating is required.
Key Features and Benefits
- Delivers a powerful 300W output at 12V DC for large-scale LED projects
- Universal 100-277V AC input ensures compatibility with a wide range of electrical systems
- Integrated junction box for streamlined installation and wiring
- Non-dimmable design for applications where primary side dimming is not needed
- Built-in protections against short circuit, over-current, over-voltage, and over-temperature
- Slim, compact aluminum housing is only 1.92” tall for easy placement
- Wet location rated and cULus listed for reliable outdoor use
- High efficiency (>88%) and free air convection cooling for long life
- Class 1, Class P, Type HL, FCC compliant for safety and performance
Specifications
- Input Voltage: 100-277VAC
- Output Voltage: 12VDC
- Maximum Load: 300W
- Minimum Load: 30W
- Efficiency: >88%
- Power Factor: 0.95
- Dimensions: 10.95” L x 4.33” W x 1.93” H
- Operating Temperature: -40°F to 140°F (-40°C to 60°C)
- cULus Listed for Wet Locations
Common Uses
Ideal for powering LED tape lights, linear lighting, DMX-controlled installations, architectural accent lighting, and outdoor LED projects requiring reliable, wet-location rated power supplies.
