Ultra bright energy efficient, long life Red or Green LED Exit sign illumination.
Two fully ajustable high performance premium grade, ultra bright white LED lamps.
3 watt (1 LED x 3 watts) per head.
ELECTRICAL
Dual 120/277 voltage.
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
8.4V long life, maintenance-free, rechargeable NiCd battery.
Internal solid-state transfer switch automatically connects the internal battery to LED board and LED lamp heads for minimum 90-minute emergency illumination.
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Aluminum mounting canopy included for top or end mount.
Universal knockout pattern on back plate for wall mount.
HOUSING
Unique design provides spec grade EXIT sign with LED lamp heads in one low profile housing.
Premium-grade, extraded aluminum housing (also available in black or white powder-coated finishes).
Field selectable knockout Chevron directional indicators.
Quick-snap face plate closure.
Unique design allows double face conversion in the field.
OPTIONS RC: Remote capacity of up to 3.0 watts.
WARRANTY / LISTING
Five year warranty on all electronics and housing. Battery proated for five years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA Local and State Codes.
