Volumetric troffer with 4000K selectable color temperature and 49L adjustable lumen output.
Key Features and Benefits
- Architecturally designed volumetric troffer
- Lightweight aluminum matte white finish body
- High transmission extruded PMMA frosted acrylic lens
- Recessed, Surface or Flange Mount
- Air Return Options
- Advanced Wireless Controls Options
- 2×4 size
- 2,400 – 10,000 Delivered Lumens
- High Efficacy – Up to 151 lm/W
- 4000K CCT
- 80 CRI
- Calculated L70 > 100,000 hrs
- 0-10V Dimmable Driver
- 5 Year Warranty (std)
- ETL Listed
- DesignLights Consortium Qualified Luminaire
Specifications
- Lightweight aluminum matte white finish body
- Class 2 LED light engine
- Power Factor > 0.90
- Standard 120-277 VAC 0-10V dimmable (10% – 100%)
- 1% dimming driver standard on optional 347V High Voltage (HV) drivers
- Optional Sensor Ready and DALI Ready drivers
- Optional Bi-level dimming driver (100% / 50%), 1% Dimming driver and Lutron Hi-Lume 1% dimming driver
- Fits into standard 15/16″ & narrow 9/16″ T-grid ceiling
- Optional Flange Kit (FLGK) for recessed drywall mounting & Surface Mount (SM) to ceiling mount options
- Access plate installed on top of fixture for easy hardwire power connections
- Optional factory installed power flex conduit whip (WHIP)
- Standard high transmission extruded PMMA frosted acrylic volumetric lens
- Removable lens for easy access to LED boards and drivers
- Factory installed advanced sensor options available
- ETL Listed to US & Canadian safety standards
- Suitable for damp locations
- Type IC rated
- American Recovery & Reinvestment Act Funding Compliant
- DLC Premium Qualified, with some Standard Qualified configurations
Common Uses
Education, Healthcare, Offices, Hallways, Multipurpose Rooms, Conference Rooms
