The ESL Vision Area Light Series delivers flexible, high-performance outdoor illumination for commercial and municipal projects. This 1st generation selectable model combines multi-watt and multi-CCT control in one fixture, helping contractors simplify inventory while matching site-specific lighting needs. Built for durability and efficiency, it is a dependable choice for long-term area lighting upgrades.
Key Features and Benefits
- Field-selectable output with 100W, 120W, or 150W settings for adaptable light levels
- Selectable 3000K, 4000K, and 5000K CCT to tune visual comfort and visibility
- Rugged die-cast aluminum body with PC lens and IP65 protection for outdoor reliability
- Smooth 0-10V dimming to off for energy savings and control integration
- High efficacy up to 170 lm/W to reduce operating costs
- Backed by a 5-year warranty with UL certification and DLC Premium listing
Specifications
- Lumen Output: 25500
- Voltage: 120-277V, 277-480V
- CRI: 80+
- Frequency: 50/60
- Power Factor: >0.97@120V, >0.92@277V
- THD: <20%
- Operating Temperature: -40b0F to 122b0F (-40b0C to 50b0C)
- Rated Life (L70): 120000 hours (TM-21 calculated)
- Dimensions: 16.63″ x 8.66″ x 2.07″
- Weight: 6.2 lbs
- Surge Protection: 6kV driver
Common Uses
Ideal for parking lots, roadways, campuses, auto dealerships, perimeter security lighting, and general commercial site illumination where efficient, weather-resistant area lighting is required.
