The Westgate WPMAX Series LED Max-Feature Wall Pack is a high-performance exterior fixture built for reliable perimeter and facade illumination. Designed with selectable wattage and color temperature, this model gives contractors and facility teams flexibility to match site requirements while reducing SKU complexity. As part of Westgate’s outdoor lineup, it combines strong output, durable construction, and dark-sky-conscious optical control.
Key Features and Benefits
- Field-selectable power and CCT let you fine-tune light levels and appearance from one fixture.
- Adjustable throw settings (narrow, medium, wide) help optimize coverage and reduce wasted light.
- Prismatic borosilicate glass lens and cutoff-style design improve visual comfort and site visibility.
- Built-in photocell and pre-installed sensor socket support smarter energy-saving control strategies.
- IP65 wet-location construction with rugged ADC12 aluminum housing stands up to harsh outdoor environments.
- Certified for safety and performance with UL Listed and DLC Listed qualifications, backed by a 7-year warranty.
Specifications
- Lumen Output: 13500/18000/20250
- Wattage: 90W/120W/150W
- Voltage: 120-277V
- Color Temperature: 3000K/4000K/5000K
- CRI: 70+
- Efficacy: 135 lm/W
- Dimming: 0-10V
- Frequency: 50/60Hz
- Power Factor: >0.9
- Rated Life: 70000 hours
- Operating Temperature: -40°F to 122°F
- BUG Rating: B2-U3-G3
- Dimensions: 13.34″(W) x 8.26″(H) x 5.86″(D)
Common Uses
Ideal for building perimeters, entrances, courtyards, hotel exteriors, industrial facilities, and general wall-mounted outdoor security lighting in commercial and residential settings.
