The American Lighting DIP 360 Gimbal is a versatile recessed downlight designed for directional accent and general illumination in one compact fixture. As part of the DIP gimbal series, it combines field-selectable color temperature with full aiming flexibility, making it a practical choice for both new construction and remodel projects.
Key Features and Benefits
- True 360° gimbal design allows precise light aiming for task, accent, or wall-wash effects.
- Built-in 5CCT selection (2700K/3000K/3500K/4000K/5000K) simplifies inventory and on-site tuning.
- Smooth TRIAC dimming supports broad light-level control for comfort and energy savings.
- Wet-location and Type IC rated construction supports use in insulated ceilings and moisture-prone areas.
- Long 50,000-hour rated life reduces maintenance frequency over time.
- Backed by a 5-year limited warranty and certified to cETLus, Energy Star, FCC, and JA8 standards.
Specifications
- Lumen Output: 880|910|930|1000|960
- Wattage: 14W
- Voltage: 120V
- Color Temperature: 2700K|3000K|3500K|4000K|5000K
- CRI: 90
- Beam Angle: 110°
- Dimming Type: Phase (TRIAC, 10-100%)
- Rated Life (70 Hours): 50000
- Operating Temperature: -20°C to 40°C
- Finish / Color: White
- Mounting: Recessed with spring-loaded clips
Common Uses
Ideal for residential and light commercial interiors such as kitchens, living areas, hallways, hospitality spaces, and covered wet-location applications where adjustable beam direction and selectable CCT are important.
