4-Inch LED IC Airtight Frame-In Recessed Housing

AVAILABLE MODULES

DESIGN FEATURES

ELECTRICAL

• Dimmable compatible with conventional dimming systems
• Trims include E-26 socket adapter for retro fit use

HOUSING

• Sturdy steel construction
• Suitable for use in new construction applications
• IC Rated for direct contact with batt type fiberglass insulation
• Thermally protected against improper lamping
• 5-9/16” height allows use in 2” x 6” joist construction
• Adjusts to accommodate up to 1” ceiling thickness

JUNCTION BOX

• J-Box is listed for through-branch circuit wiring (4in – 4out) and seven 1/2” knockouts
• 3 port quick connectors pre-installed in all J-boxes

BAR HANGER

• Pre-installed bar hangers allow the housing to be positioned at any point within 24” joist span
• Pre-installed captive nails on bar hangers
• Bar hangers can be turned 90° on the plaster frame
• Bar hangers are designed to fit T-bar spine without additional clamps for use in drop ceilings

DIMENSIONS

• Size: H 6” x L 6-7/8” x W 6-1/8”
• Aperture: 6-1/8”

CERTIFICATIONS

• cCSAus listed for damp location and feed through wiring
• Meets Washington State energy code for restricted airflow requirements
• 5 year limited warranty
