The MaxLite Network Node Rectangular with PIR Motion Sensor and Daylight Harvesting (Silvair) is a sophisticated lighting control solution designed to enhance energy efficiency and user convenience in various settings. This model, NN-RTPSW-SL, is part of MaxLite’s innovative c-Max Network Partners series, integrating with Silvair’s Bluetooth NLC technology.
Key Features and Benefits
- Luminaire Level Lighting Control enabled with wireless Bluetooth NLC
- Simple Plug-and-Play Connection with USB-C receptacle
- PIR Motion Sensor and Daylight Harvesting capabilities
- Multi-level dimming and customizable dimming scenarios
- Time clock scheduling and high-trim tuning
- Robust design with vandal-resistant locking screw
- 5 Year Warranty
Specifications
- Dimensions: 58 mm x 20.8 mm x 20.5 mm
- Weight: 0.45 oz
- Operating Voltage: 12Vdc
- Operating Current: max 15mA
- Sinking Current: max 25mA
- Control Output: Analog 0-10V (Linear)
- Wireless Standard: Bluetooth NLC v2.30+
- Operating Temperature: -40°F to 130°F / -40°C to 55°C
- Color: White
- Cybersecurity: ioXt Certified
Common Uses
Ideal for offices, hospitals, schools, warehouses, industrial settings, and retail environments where advanced lighting control is desired.
