Narrow Lens REL23 Series Emergency Unit with Cold Weather Option

This compact low profile, high output, self-contained emergency unit is part of the RP Lighting and Fans REL23 Series. Its self-diagnostic feature and cold weather option make it a reliable safety fixture for various environments. With two adjustable 1.4W LED heads, it provides a total of 247 lumens, ensuring visibility during power outages.

Key Features and Benefits

• Self-diagnostic system monitors battery, charger, and lamp status
• Adjustable clear lens LED heads for optimal light distribution
• 3.6V, 800 mAh, rechargeable Ni-Cad battery with a 48-hour recharge time
• 90 minutes of emergency illumination
• UL Listed for damp locations to UL 924 standards
• 5-year limited warranty on LED light source, 1-year on other components

Specifications

• 120/277V AC dual voltage operation
• Cold Weather Option: -10°C (14°F) to 40°C (104°F)
• Standard Operating Temperature: 10°C (50°F) to 40°C (104°F)

Common Uses

Suitable for a variety of applications including hallways, large spaces, and areas requiring emergency lighting with wider unit spacing. The cold weather capability allows for use in environments with lower temperatures.
