The MaxLite BLHE Economic Linear High Bay Gen 3 is a value-driven fixture engineered for demanding commercial and industrial lighting projects. As part of MaxLite’s ECO Series, it combines high output, dependable performance, and flexible mounting for large open interiors where efficiency and visibility are critical.
Key Features and Benefits
- High-output performance delivers up to 40,800 lumens to effectively illuminate high-ceiling applications.
- Energy-saving 0-10V dimming capability supports reduced power use and better lighting control.
- Durable frosted PMMA lens helps provide smooth light distribution and visual comfort.
- Flexible installation with suspension or surface mounting options; V-hook and 40″ knotted chain included.
- Built for reliability with DLC Premium qualification and cULus/FCC/RoHS compliance.
- Backed by a 10-year standard warranty with labor allowance for long-term peace of mind.
Specifications
- Wattage: 300W
- Input Voltage: 347-480V
- Color Temperature: 5000K
- CRI: ≥80
- Lumen Output: 40,500-40,800 lm
- Efficacy: 135-136 lm/W
- L70 Rated Life: 100,000 hours
- Power Factor: ≥0.9
- Operating Temperature: -4°F to 122°F (-20°C to 50°C)
- Environment: Dry and damp locations
- Housing Material: Galvanized steel
- Finish: White electrostatic powder coat
Common Uses
Ideal for warehouses, gymnasiums, distribution centers, manufacturing facilities, and big-box retail spaces requiring high lumen output, long life, and efficient operation in dry or damp indoor environments.
