The SENSORWORX family of wall switch occupancy/vacancy sensors provides a simple and cost effective lighting control solution for many applications. Just like its line voltage counterpart the low voltage SENSORWORX 0-10V dimming wall switch sensor is designed with contractors in mind. Less than 1″ deep, the unit is 25-40% shallower than typical dimmers and sensors, resulting in less crowed wall boxes. SENSORWORX products utilize the latest passive infrared technology and digital signal processing techniques to provide unmatched motion detection performance. These units are also available with an integrated microphone to provide overlapping passive acoustic occupancy detection for rooms with obstructions or where occupant motion is limited. For dimming adjustment, intuitive raise and lower buttons are present in additional to an on/off button.
FEATURES
PHYSICAL FEATURES
Enclosure is 25-40% Shallower than Other Sensors (<1″ Depth into Wallbox)
Unique Bat-Wing Shaped Lens ProvidesEnhanced Peripheral Detection
Modern Look and Intuitive Easy-Tap Buttons for On/Off, Raise, & Lower
Rugged Vandal Resistant Lens
Settings are Adjustable Without Removing Cover Plate
OPERATIONAL FEATURES
Compatible with 0-10V Dimmable LED, and Fluorescent Lighting
Wall-to-Wall Passive Infrared Small Motion Detection
Passive Acoustic Detection (Optional)- Prevents False Offs when No Motion Is Present
100% Passive Detection Methods- No Interference Potential from External Devices
Configurable Sensor Settings Including Time Delays and Occupancy/Vacancy Operating Modes
COVERAGE PATTERNS
30” to 48” (0.76 – 1.22 m) recommended mounting height
Wall to wall (~180 degree) coverage
Small motion (e.g., hand movement) detection up to 20 ft (6.10 m), ~625 ft²
Large motion (e.g., walking) detection greater than 36 ft (10.97 m), ~ 2025 ft²
Overlapping acoustic detection of occupants over entire coverage area
Advanced signal processing filters out nuisance noises while not effecting overall sensitivity
APPLICATIONS
A wall switch sensor is typically used to retrofit an existing wall switch in a small room or enclosed space. A Passive Infrared (PIR) only sensor is sufficient for spaces where line of site is maintained and occupants are periodically moving (e.g., copy rooms, storage rooms). Dual technology sensors are necessary where occupants may be partially blocked from the sensor’s direct view or where they may be stationary (e.g., private offices or restrooms with stalls).
Private Restrooms
Copy Rooms
Restroom with Stalls
Small Meeting Room
Small Office
Vestibule
Storage Room
Break Room
SPECIFICATIONS
Operating Voltage: 120/277 VAC, 50/60 Hz
Load Ratings: MAX: 800W @ 120VAC|1200W @ 277VAC MIN: None
Load Types: LED Driver/Lamps CFL, Electronic/Magnetic Ballasts (Fluorescent), Tungsten (Incandescent)
Dimming Compatibility: 0-10 VDC ballasts or drivers compliant with IEC 60929 Annex E.2
Dimming Load: – 50 mA (sink only)
Operating Temp: 32°F to 122°F (0°C to 50°C) – Standard, -40° F/C (with -HE Option)
Relative Humidity: 0-95% Non-Condensing, Indoor Use Only
Mounting: Single Gang Switch Box
