The Lotus LED Lights SDD-24096-CCT is a compact 3-in-1 control solution that combines a constant-voltage LED driver, dimmer, and manual CCT controller in one in-wall device. Designed for tunable white 24V tape light systems, it simplifies installation while improving compatibility between controls and LED loads. As part of Lotus LED’s tape lighting ecosystem, it offers reliable performance for modern residential and commercial lighting projects.
Key Features and Benefits
- All-in-one design integrates driver, dimming, and CCT adjustment to reduce component count and wiring complexity.
- Manual slide control enables smooth tunable white adjustment from warm to cool light for flexible ambiance.
- Supports both single-pole and 3-way wiring for versatile control layouts in rooms and corridors.
- High power quality with strong power factor and low THD helps maintain stable, efficient operation.
- Built-in protection package includes short-circuit, over-voltage, over-heat, and over-load safeguards.
- Backed by a 5-year warranty and certified to UL/cUL, FCC, and Class 2/Class P requirements for dependable code-ready use.
Specifications
- Wattage: 96W
- Input Voltage/Frequency: 120V AC, 60Hz
- Output: 24V DC / 4A
- Output Voltage Adjustment: 24V-26V (±0.5V)
- Dimming Range: 0.3%-100%
- PWM Frequency: 16KHz
- Power Factor: >0.99 at full load
- THD: <10% at full load
- Efficiency: 91% at full load
- Operating Temperature: -40°F (-40°C) to +140°F (+60°C)
- Location Rating: Dry and Damp locations
- Weight: 0.55 lbs
Common Uses
Ideal for tunable white LED tape installations in homes, hospitality spaces, retail displays, and accent lighting applications where in-wall control, smooth dimming, and adjustable white color are required.
