Ultra bright, energy efficient white LED emergency lighting.
4.5 watt (36 LEDs x 0.125 watts) per light pipe.
Adjustable high performance, smooth-plated, metalized reflector and acrylic, UV-stabilized “Light Pipe lens for optimal light distribution.
Long life energy efficient Red or Green LED Exit sign illumination.
ELECTRICAL
Dual 120/277 voltage.
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
4.8V long life, maintenance-free, rechargeable NiCd battery.
Remote capacity of 3.0 watts standard.
Internal solid-state transfer switch automatically connects the internal battery to LED board and LED light Pipe for minimum 90-minute emergency illumination.
MOUNTING
EZ-snap mounting canopy included for top or end mount.
Universal knockout pattern on back plate for wall mount.
HOUSING
Injection-molded, engineering grade, 5VA flame retardant high-impact resistant, thermoplastic in white or black finishes.
EZ snap-out Chevron directional indicators.
OPTIONS
SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meets electrical and life safety codes.
Custom: Signs available with requested “special” wording.
WARRANTY / LISTING
Five year warranty on all electronics and housing. Battery prorated for five years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
