The ESL Vision HaloFlex Series round high bay is a versatile, performance-driven fixture designed for demanding commercial and industrial environments. This configuration combines selectable wattage and CCT in one SKU, helping contractors and facility teams simplify inventory while dialing in light levels on site. As part of ESL Vision’s high bay lineup, it delivers strong output, robust protection, and control-ready functionality for modern lighting upgrades.
Key Features and Benefits
- Field-selectable power and color temperature for flexible commissioning and retrofit adaptability
- High-output performance up to 31,087 lumens with efficacy up to 155 lm/W for energy savings
- 0-10V dimming with 12V auxiliary support for advanced control integration
- Rugged die-cast housing and optical-grade polycarbonate lens for long-term durability
- IP65-rated construction with 6kV surge protection for reliable operation in harsh conditions
- Certified to UL, DLC Premium, and FCC standards with a 5-year warranty for confidence and compliance
Specifications
- Lumen Output: 31087
- Wattage: 100W|150W|200W
- Voltage: 120-277V
- Color Temperature: 3500K|4000K|5000K
- CRI: 80
- Frequency (Hz): 50/60
- Power Factor: 0.95
- THD: 20
- Max Ambient Temperature: 122°F (50°C)
- Rated Life (70 Hours): 54000
- Beam Angle: 90°
- IP Rating: IP65
- Dimensions: Ø12.56″ x 4.84″
- Weight: 5.73 lbs
Common Uses
Ideal for warehouses, manufacturing facilities, gymnasiums, distribution centers, and other high-ceiling indoor or semi-protected spaces requiring efficient, high-lumen illumination with control compatibility.
