ESL Square Canopy Series, 60W/75W/90W, 3000K/4000K/5000K

The ESL Square Canopy Series is a versatile surface-mount lighting solution designed for commercial exterior and semi-exterior applications. This 5th generation model combines field-selectable wattage and CCT in one fixture, helping contractors and facility teams simplify inventory while matching site lighting needs. Built for long service life and dependable performance, it is a key option in ESL Vision’s canopy lineup.

Key Features and Benefits

• Selectable output with three wattage settings (60W/75W/90W) for flexible light levels
• 3-CCT adjustability (3000K/4000K/5000K) to tune visual comfort and site appearance
• 0-10V dimming to off for energy savings and control integration
• High efficacy up to 145 lm/W to reduce operating costs
• DLC Premium listed and UL certified for trusted commercial compliance
• Backed by a 5-year warranty for long-term reliability

Specifications

• Lumen Output: up to 13050
• Input Voltage: 120-277V
• CRI: >80
• Beam Angle: 190°
• Frequency: 50/60
• Power Factor: >0.9
• THD: <20%
• Operating Temperature: -40°F to 113°F (-40°C to 45°C)
• Rated Life (L70): 170000 hours (TM-21 calculated)
• Dimensions: 9.57″ x 9.57″ x 3.62″
• Weight: 5.07 lbs
• Surge Protection: 2.5kV

Common Uses

Ideal for gas station canopies, parking garage ceilings, covered drive lanes, entry canopies, and other commercial soffit-mounted outdoor areas requiring durable, efficient illumination.
