The Endeavour 4′ Linear High Bay is a top-tier lighting solution designed for industrial and commercial applications. It delivers 12,000 lumens with a selectable 5000K color temperature, ensuring bright and clear illumination.
Key Features and Benefits
- Sleek curved polycarbonate injection molded end caps
- Aluminum body with steel channel for added rigidity
- Toolless hinged driver access
- Narrow distributions
- V-Clips for dual point chain or cable hanging (standard)
- 131°F standard ambient temperature range
- 5000K CCT
- Uplight options to optimize full room illumination
- 17 size/lumen packages
- >80 Color Rendering Index (CRI)
- Calculated L70 > 100,000 hrs
- 0-10V dimmable driver (100% – 10%)
- 5-year warranty (standard)
- ETL listed for damp location
- DesignLights Consortium® Premium Qualified Luminaire
Specifications
- Part Number: EDV4-12L-U-50-ND
- Lumens: 12,000 lm
- Color Temperature: 5000K
- Distribution: Narrow
- Fixture Lumens: 11,277 lm
- Wattage: 102W
- Efficacy: 111 lm/W
- Mounting: Pendant
- Spacing Criteria: 0° = 1.29, 90° = 1.29
- Dimensions: 48.01″ x 22.20″ x 4.00″
- Weight: 16.21 lbs
Common Uses
Ideal for gymnasiums, manufacturing facilities, warehouses, distribution centers, hangars, retail spaces, government facilities, and auto service bays/lanes.
