The EiKO AAL1 Area Light combines a slim architectural profile with flexible output and optical choices for demanding outdoor applications. This versatile series brings efficient, controls-ready LED illumination to parking areas, roadways and other large spaces.
Key Features and Benefits
- PowerSet technology offers selectable 300W, 240W and 200W output to tailor illumination and energy use.
- FieldCCeT models offer selectable color temperatures, while this model provides crisp 3000K light.
- T5 optics help direct light across outdoor areas; multiple mounting options are available separately.
- Controls-ready screw-in receptacle and 0-10V dimming simplify adding lighting controls.
- UL Listed for the US and Canada, RoHS and FCC compliant, and DLC Premium qualified.
- Backed by a 5-year limited warranty.
Specifications
- Wattage: 300W/240W/200W
- Lumen output: 42,000/33,600/28,000
- Efficacy: 140 lm/W
- Color temperature: 3000K
- CRI: >80
- Input voltage: 120-277V
- Dimming: 0-10V, dim-to-off
- Power factor: >0.9
- Total harmonic distortion: <20%
- Estimated rated life: 100,000 hours at L70
- Distribution optic: T5
- Environmental protection: IP65 and IK08; 3G rated per ANSI C136.31
- Ambient operating temperature: -40°F to 122°F (-40°C to 50°C)
- Surge protection: 10kV included; 20kV optional
- Auxiliary output: 12VDC, 100mA maximum
- Housing: bronze powder-coated die-cast aluminum
- Lens: impact- and UV-resistant polycarbonate
- Installation details: includes a pre-installed 3.3′ (1 m) power cord and one 1/2″ side knockout; mounting hardware sold separately
Common Uses
Suitable for parking lots, automotive dealerships, roadways, campuses, streetscapes, airports, building facades, signs, entryways and area security lighting.
