The EiKO AAL1 series is a controls-ready architectural LED area light platform built for demanding outdoor site and roadway applications. This configured model delivers selectable power levels with a high-efficacy optical system and robust environmental protection, making it a dependable choice across commercial and municipal projects.
Key Features and Benefits
- PowerSet flexibility enables 100W, 80W, or 60W operation from one fixture for easier field tuning.
- Controls-ready design with screw-in receptacle simplifies future sensor or networked control upgrades.
- Rugged outdoor construction with IP65 ingress protection and IK08 impact resistance supports long-term reliability.
- DLC Premium qualification helps maximize rebate eligibility and energy performance goals.
- 0-10V dim-to-off capability supports advanced lighting control strategies and additional energy savings.
- Backed by a 5-year limited warranty for added project confidence.
Specifications
- Lumen Output: 14000/11200/8400
- Wattage: 100/80/60W
- Voltage: 120-277V
- Color Temperature: 4000K
- CRI: 80+
- Distribution Type: Type V
- Efficacy: 140 lm/W
- Rated Life (L70): 100000 hours
- Power Factor: >0.9
- THD: <20%
- Dimming: 0-10V, dim-to-off
- Operating Temperature: -40b0C to 50b0C
- Housing: Die-cast aluminum
- Lens: UV-resistant polycarbonate
- Finish: Bronze powder coat
- IP/IK Rating: IP65 / IK08
Common Uses
Ideal for parking areas, automotive dealerships, campuses, streetscapes, airports, building facades, entryways, signage, and general area security lighting where high output and durable outdoor performance are required.
