SERIES SUMMARY
| Model # |
Voltage |
Wattage |
CRI |
Lumen |
Dimension(LxWxH) |
Energy Star |
| DC028D |
120-277V |
35W |
>80 |
2700 |
28.3″ x 14.1″ x 3.8″ |
Yes |
| DC032D |
120-277V |
46W |
>80 |
3750 |
32.3″ x 18.1″ x 4.3″ |
Yes |
DESIGN FEATURES
HOUSING
- Die-formed Cold-rolled Steel
- Finish Option: -62 Satin Nickel, -01 Polish Brass, -06 White, -30 Oil Rubbed Bronze
OPTICAL
- Shade: High Transmission Acrylic Create Excellent Light Distribution and Uniformity.
- LED: High Efficiency, High CRI, Binned and Mixed to Reach Uniform Light
ELECTRICAL
High Power Factor, Low THD
LAMP
- LED Type: Built-in (More Color Temperature Option – 3500K, 5000K)
- CFL Type: Circline or T8 Lamp (More Color Temperature Option – 2700K, 4000K)
CERTIFICATIONS
5 Years Warranty on Driver and LED Module
