Westgate Manufacturing WMXE Series Outdoor Wall Pack Light
The Westgate Manufacturing WMXE Series brings high-performance and flexibility to outdoor lighting applications, making it an ideal choice for replacing traditional HID wall packs. Perfect for diverse settings such as alleys, loading docks, doorways, pathways, and parking areas, this fixture ensures consistent, bright illumination.
Key Features and Benefits
- Prismatic borosilicate glass lens for optimal light distribution, ensuring maximum visibility.
- Durable ADC12 aluminum heat sink with outdoor powder coating for long-lasting durability.
- Multi-power switch with selectable lumen outputs (80W, 100W, and 120W) for customizable brightness.
- Integrated photocell for automated dusk-to-dawn lighting control.
- Exceptional lifespan of 70,000 hours backed by a 7-year warranty.
- IP65 rated for wet locations, offering excellent weather resistance.
- High efficacy of 140 lumens per watt, providing energy-efficient illumination.
Technical Specifications
- Color Temperature: 5000K
- Selectable Total Lumens: 11200LM to 16800LM Max
- Dimming Capability: 0-10V Dimming
- Input Wattage: 80W/100W/120W (Selectable)
- Input Voltage: 120-277V AC 50/60Hz
- Color Rendering Index (CRI): >70
Common Uses
The WMXE Series is versatile for various outdoor lighting needs, commonly used for illuminating pathways, parking lots, and building exteriors. Its high efficacy and durability make it a top choice for commercial and industrial environments.
