The ATG Helix G4 Plus is a high-performance LED round high bay designed for demanding commercial and industrial environments. As part of ATG’s Gen4 lineup, it combines field-selectable power and CCT in one fixture to simplify stocking and project flexibility.
Key Features and Benefits
- Selectable output with three wattage settings (300W/240W/200W) for on-site light level tuning
- Tri-CCT selection (3000K/4000K/5000K) supports varied visual comfort and task requirements
- IP65 construction and 6kV surge protection help ensure reliable operation in harsh locations
- 0-10V dimmable driver with 12V AUX tap and pre-installed receptacle supports controls integration
- DLC Premium listing and a 10-year warranty support energy rebates and long-term value
Specifications
- Lumen Output: 29256|30180|30796|34170|35249|35968|40715|42001|42858
- Voltage: 120-277V
- Wattage: 200W|240W|300W
- Color Temperature: 3000K|4000K|5000K
- Efficacy: 136|141|144|146|151|154|157|152|160 lm/W (approx. by setting/CCT)
- Beam Angle: 100°
- Max Ambient Temperature: 55°C (131°F)
- Rated Life (L70): 136000 hours
- Dimensions: 15.35″ diameter; height 7.8″/8.4″ (without sensor), 8.7″/9.3″ (with sensor)
Common Uses
Ideal for warehouses, gymnasiums, manufacturing plants, retail back-of-house areas, distribution centers, hangars, and workshops requiring high lumen output, durability, and controllability.
