The Aleo SHF-OSDL/BT-PP3-DC-312 is a cutting-edge Bluetooth high frequency occupancy sensor with daylight harvesting, designed for seamless integration into indoor lighting systems. This sensor brings together motion detection, ambient light sensing, and wireless Bluetooth NLC controls in a compact, plug-and-play package, making it a standout in Aleo’s smart controls lineup.
Key Features and Benefits
- Bluetooth NLC wireless mesh for scalable, reliable lighting control
- High-frequency microwave sensing detects motion even through some non-metallic materials
- Integrated daylight harvesting for optimized energy savings
- 0-10V dimming control for flexible lighting adjustments
- Plug-and-play installation with quick connector
- Remote and magnetic reset options for easy maintenance
- Robust, decentralized control with no single point of failure
- Supports energy code compliance and future-proof software updates
- Intuitive app-based setup and management
Specifications
- Input Voltage: 10-14V DC
- Input Current: >50mA
- Microwave Frequency: 5.8GHz ±75MHz
- Mounting Height: Up to 12ft (4m)
- Bluetooth Range: Up to 100ft (30m)
- IP20 rated for indoor use
- Operating Temperature: -40°F to +158°F (-40°C to +70°C)
- Compatible with dim-to-off LED drivers
- 5-year limited warranty
Common Uses
Perfect for open offices, private offices, conference rooms, classrooms, retail spaces, hospitals, and lobbies—anywhere smart, efficient lighting control is needed.
