5″ Ultimate J-Box Mount LED, 10W, 5CCT, Round Black Trim

This 5″ Ultimate J-Box Mount LED is a versatile lighting solution ideal for multi-family and residential applications. With its selectable color temperature (5CCT) and high CRI, it ensures true color rendering and adaptability to various settings. The interchangeable round black trim offers a sleek and modern design, while the fixture’s compatibility with most 4″, 4/0 & 3/0 junction boxes makes installation straightforward and efficient.

Key Features and Benefits

• 5 selectable color temperatures (2700K, 3000K, 3500K, 4000K, 5000K)
• Up to 740 lumens output with a CRI of 90+ for accurate color representation
• Energy-efficient 10W LED equivalent to a 75W halogen bulb
• Dimmable with TRIAC dimmers from 5% to 100%
• Wet location certified, suitable for use in soffits
• Fire rated when used with a fire rated junction box
• Projected life of 50,000 hours maintaining 70% light output
• Comes with a 5-year warranty

Specifications

• Power Consumption: 10W
• Beam Angle: 60° (standard), 38° (optional)
• Input Voltage: 120V AC 50/60 Hz
• Ambient Operating Temperature: -4°F to +104°F
• Dimensions: OD 5 1/4″, Depth 1 1/2″, Visible Trim Thickness 1/8″

Common Uses

Ideal for residential lighting including living rooms, kitchens, and bedrooms as well as in commercial settings where a recessed look with minimal visibility is desired.
