20A Brass Square Tamper-Resistant GFCI Receptacle

Brass square pop-up floor box assembly with 20A tamper-resistant GFCI receptacle, available in gold finsh, easy connection wiring accepts #12-10 AWG stranded and solid copper wire, steel floor box must be flush with sub-wood or carpeted floor, 2 years limited warranty.
DESCRIPTION
The Square Pop-up Floor Box Assembly offer two confi guration with 20A USB, or GFCI Receptacle. These are used for carpet and wood fl oors. Pop-up covers provide easy access to power and can be snapped closed when not in use. Kit assembly includes a metal fl oor box, choice of 20A USB, 20A GFCI or 20A TWR receptacle.
FEATURES

20A 125A USB receptaclewith 2.1Amp Total
20A 125V GFCI or 20A TWR
Easy connection wiring accepts # 12-10 AWG stranded and solid copper wire
For use with carpet and wood floors, Also great for counter-top application.
Steel floor box must flush with subwood or carpeted floor.

TESTING & CODE COMPLIANCE

2011 NEC Article 406.12 for tamper-resistant receptacles
2011 NEC Article 314.27 for floor boxes
All receptacles are UL listed

SPECIFICATIONS
COVER

Cover Material: Brass(C) or Nickel-Plated Brass(S)
Cover type: square

COVER SIZE

961243: 5”x5.5”
Receptacle Rating: 20A USB 2.1Amp Total, 20A GFCI
